In the foreground is a horseman knocked from his mount by a large stone missile, purportedly from a trebuchet atop the castle wall.

To the right is a bow powered catapult .

To the left  is a hinged counterweight trebuchet . The view shows the block and tackle for gaining  mechanical advantage when drawing the beam into the cocked position as well as the hinged counterweight cabinet and sling.

The small counterweight, perpendicular to the main cabinet, is designed to damp the swing of the beam, allowing a greater rate of fire.
